Many CNC Laser Cut Machine
Unique
features: Lens positioning,
the machine automatically offset
centering
![](8050L_Hp.jpg)
1200B_L Laser Cut CNC
8050L Laser Cut CNC(1200x1200mm)
(800x500mm)
Auto
Floating Focus Laser CNC (5' x 10')
Z axis will
go up and down follow the uneven board.
![](lasercut4.JPG) ![](lasercut9.JPG)
![](lasercut_5.jpg)
Specification
Drive Motor |
Servo Motor/Stepper Motor |
Laser Power |
50W/60W/70W/100W/130W |
Laser Type |
CO2 Sealed Laser Tube, water-cooled, 10.6um |
Min-laser beam |
0.4 mm |
Position Accuracy |
+/-0.018 mm |
Resolution |
0.008 mm |
Rapid Rate |
12000 mm/min |
Cutting Speed |
25-10000 mm/min |
Power Requirement |
220V 50-60Hz |
Motion Control |
EasyCut |
Support File |
G-Code file (NC, CNC, ISO, tool path file) |
Applicable Materials |
wood, plastic, acrylic, leather, paper, double color
board, ABS boards, resin, animal grease, anodized aluminum (engraving) etc |
|
